| Gama | Uniview |
| Sensor | 1/2.7” Progressive Scan CMOS |
| Resolución | 5MP |
| Main Stream | 5MP@25fps: 2880×1620; 5MP@20fps: 2592×1944 |
| Extra Stream | 4MP: 2560×1440; 2MP: 1920×1080 |
| Lente | 2.8 mm |
| Iluminación mínima | 0.02 Lux (Color) |
| Alcance IR | 20 m |
| Mejoras | BLC, HLC, DWDR, DAY/NIGHT, SMART IR |
| Día/Noche | Filtro mecánico ICR |
| Alimentación | DC 12 V / 5.04 W |
| Salida vídeo | TVI: 5MP@20fps; AHD: 5MP@20fps; CVI: 5MP@25fps CVBS: PAL, NTSC |
| Interface | 5.5 mm |
| Temp. funcionamiento | -30 C ~ 60 C |
| Protección | IP67 |
| Dimensiones | Φ142mm × 63mm × 65mm |
| Peso | 145 g |
